M Pumps: Hermetic metal and plastic magnetic drive pumps
Since 2006 Drotec distributes in Argentina the M Pumps magnetic coupling pumps manufactured in Italy.
M Pumps offers a wide range of hermetic pumps without losses: centrifugal, regenerative turbine and positive displacement sliding vanes. They are available in both metal and plastic versions.
The main applications are: pumping of acids and bases, hydrocarbons, thermal fluids, aggressive, radioactive, explosive and toxic liquids and any other application in which it is desired to handle "difficult" fluids without lickings or emissions and in total safety.
For more information contact us to drotec@drotec.com.ar or fo to www.3mpumps.com
Serie CN MAG M API
According to API 685 standards
Flow: hasta 1000 m3/h
Pressure: up to 220m
Maximum temperature: 350°C
Materials in contact with the liquid
AISI 316, steels, bushings and sleeves in Silicon Carbide, Hastelloy. Upon request executions in superalloys and special materials.
Serie CM MAG M
According to ISO 2858/DIN 24256 standards. Available in a monoblock version or coupled on an electric motor basis.
Flow: hasta 1000 m3/h
Pressure: up to 220m
Maximum temperature: 350°C
Materials in contact with the liquid: AISI 316, steels, bushings and sleeves in Silicon Carbide, Hastelloy. Upon request executions in superalloys and special materials.
Serie CN MAG M
Non-standard monoblock pumps.
Flow: hasta 40 m3/h
Pressure: up to 35m
Maximum temperature: 120°C
Materials in contact with the liquid: AISI 316, steels, bushings and Silicon Carbide sleeves.
Plastic Centrifugal Pumps
Series C MAG P
In monoblock construction
Flow: hasta 100 m3/h
Pressure: up to 44m
Maximum temperature: 90°C
Materials in contact with the liquid: Polypropylene or PVDF. Bushings and shafts in Alumina Ceramic and PTFE w/coke.
Series CSP MAG P
Self-priming centrifugal pumps in monoblock construction.
Flow: hasta 100 m3/h
Pressure: up to 44m
Maximum suction capacity: 5 m
Maximum temperature: 90°C
Materials in contact with the liquid: Polypropylene or PVDF. Bushings and shafts in Alumina Ceramic and PTFE w/coke.
Series CM MAG P
In monoblock construction
Flow: hasta 44 m3/h
Pressure: up to 35m
Maximum temperature: 60°C
Materials in contact with the liquid: Polypropylene or PVDF. Bushings and shafts in Alumina Ceramic and PTFE w/coke.
Serie T MAG M – TURBOMAG
Available in monoblock construction.
Flow: hasta 10 m3/h
Pressure: up to 110m
Maximum temperature: 200°C
Materials in contact with the liquid: AISI 316, steels, bushings and sleeves made of Silicon Carbide/special Carbon.
Serie CT MAG MS
Regenerative pump for low available ANPA values (0.5m) and high pressures. Available in monoblock construction.
Flow: hasta 10 m3/h
Pressure: up to 500m
Maximum temperature: 350°C
Materials in contact with the liquid: AISI 316, steels, bushings and sleeves in Silicon Carbide, Hastelloy. Upon request executions in superalloys and special materials.
Serie CPP MAG M
Multistage regenerative pump. Available in monoblock construction.
Flow: hasta 10 m3/h
Pressure: up to 1000m
Maximum temperature: 200°C
Materials in contact with the liquid: AISI 316, steels, bushings and sleeves in Silicon Carbide, Hastelloy. Upon request executions in superalloys and special materials.
Serie CN MAG M
Regenerative pump for low ANPA values available (0.5m). Available in monoblock construction.
Flow: hasta 10 m3/h
Pressure: up to 160m
Maximum temperature: 350°C
Materials in contact with the liquid: AISI 316, steels, bushings and sleeves in Silicon Carbide, Hastelloy. Upon request executions in superalloys and special materials.
Plastic turbine regenerative pumps
Series TSP MAG P
Regenerative self-priming turbine pump. Available in monoblock construction.
Flow: hasta 15 m3/h
Pressure: up to 70m
Maximum suction height: 4 m
Maximum temperature: 60°C
Materials in contact with the liquid: Polypropylene or PVDF. Bushings and shafts in Alumina Ceramic and PTFE w/coke.
T-Series MAG P
Available in monoblock construction.
Flow: hasta 15 m3/h
Pressure: up to 70m
Maximum temperature: 60°C
Materials in contact with the liquid: Polypropylene or PVDF. Bushings and shafts in Alumina Ceramic and PTFE w/coke.
Serie V IN-LINE
Available in monoblock construction.
Flow: hasta 3 m3/h
Discharge pressure: up to 13 bar
Maximum temperature: 200°C
Materials in contact with the liquid: AISI 316, steels, bushings and sleeves made of Silicon Carbide/special Carbon.
Serie VENEMAG
Available in monoblock construction. With built-in relief valve.
Flow: hasta 3 m3/h
Discharge pressure: up to 13 bar
Maximum temperature: 200°C
Materials in contact with the liquid: AISI 316, steels, bushings and sleeves made of Silicon Carbide/special Carbon.
Series V-MULTIETAPA
Available in monoblock construction.
Flow: hasta 3 m3/h
Discharge pressure: up to 25 bar
Maximum temperature: 200°C
Materials in contact with the liquid: AISI 316, steels, bushings and sleeves made of Silicon Carbide/special Carbon.
Series VP
Available in monoblock construction.
Flow: hasta 3 m3/h
Discharge pressure: up to 4 bar
Maximum temperature: 60°C
Materials in contact with the liquid: Polypropylene or PVDF. Bushings and shafts in Alumina Ceramic and PTFE w/coke.
