Molten floating ball valve
Molten floating ball valve
- Short pattern
- Anti -expelying stem
- Senotage seal with Chevron Viva Packaging to reduce fugitive emissions
- Automatic discharge seats that eliminate pressure accumulation in body cavity
- Antistatic grounding of all metal parts
- A piece and 2 -piece body options
- Assembly according to ISO 5211
- Available in fireproof option
Floating ball valves - 1 piece
Available sizes
- 1/2″ – 6″ / DN 15 – DN 150
Pressure classes
- Asme Class 150/300
Floating ball valves - 2 -piece body
Available sizes
- 1/2″ – 12″ / DN 15 – DN 300
Pressure classes
- Asme Class 150/300
Stainless steel
ASTM A351 CF8M BODY, ASTM A182 F316, BOLA AND ASTM A182 F316, TFM1700/1600, BOARD OF THE PTFE BODY, PTFE BODY, PACKAGING OF THE CHEVRON SHEEP, PLACE OF THE A515 70 and ASTM A29 1035 lever
Carbon steel
WCB ASTM A216, ASTM ASM A105, ball and ASTM ASM A182 F316, TFM1700/1600, PTFE Body, PTFE Body, Packaging of the Chevron Slaughter, antistatic spring ASTM A313 316, ASTM PREASE A276 316, ASTM block A515 70 70 ASTM A29 1035 lever
ANSI B16.10
Face to face and end dimensions of the valves
ANSI B16.34 / ASME B16.25 / API 608 / BS 5351
Valves with flanges, threaded and with butt welding ends
API 607 / ISO 10497 / BS 6755
Especificación de ensayo de incendio para válvulas
MSS SP-6
Standard finishes for contact faces of pipes of pipes and connection flanges of valves and accessories.
ANSI B16.5 / ISO 5211
Blacks for pipes and accessories with 1/2 ″ - 12 flanges
MSS SP-61
Valve pressure tests
ASTM / ANS
Materials
ISO 15848-1
Fugitive emissions
API 598
Inspection and valve test
MSS SP-25
Standard marking system for valves, accessories and unions
MSS SP-55
Norma de calidad para piezas fundidas de acero para válvulas
